CNC Turning Lathe
cnc auto lathe manufacturer
RD-42
The Gang Type CNC Turning Lathe
- 60°High rigidity structure design
allows for efficient chip removal. - Various gang tooling option.
- Optimal design for automation
- Compact Design Structure
High precision spindle
- Angular contact ball bearings
- Max. Turning speed 6000rpm
- V-Ribbed Belt
Gang Tooling
- O.D. Holder:☐20
- I.D. Holder: Ø32 mm
- No. of Tool:6 EA
LM Guide
- Roller type linear guideway
- Rapid Traverse Rate:30/36 m/min
- X/Z Axis Stroke 450/300 mm
Basic Structure
60° Slant Bed Structure
This machine bed structure designed
remains the feature of excellent chip
disposal' and easy access to the
chuck during the tool setting in 60°
slant.
Spindle
The spindle is designed with angular
contact ball bearings.
The bearings minimize thermal
displacement even at high speeds.
Linear Guideway
The RD-42 is designed with Roller
type guideway on all axis to achieve
higher rigidity.
It reduces machining noise and
enhances productivity through faster
traverse rate.
Gang Tooling System
Reduced tool change time, productive
has improved in the machining of
small sized parts.
Auto Bar feeder
Auto Bar feeder enables automation which leads to high efficiency.
Gantry Loader
Gantry loader could go with different work stocker to achieve the automatio, it enables
machining process flexibility and productivity enhancement.
| Model | RD-42 | |
| Capability | ||
| Max. Turning Diameter | Ø 165 mm | |
| Max. Turning Length | 300 mm | |
| Bar Capacity | Ø 50 mm | |
| Axis Spec. | ||
| X/Z Axis Stroke | 450 / 300 mm | |
| Rapid Traverse Rate | X:30 / Z:36 m/min | |
| Slide Type | Linear Motion Guide | |
| Spindle | ||
| Chuck Size | 6” inch | |
| Spindle Nose | A2-5 | |
| Spindle through Hole Diameter | 61 mm | |
| Max. Spindle Speed | 6000 rpm | |
| Spindle Motor Power | 7.5 / 11 / 15 KW (cont. / 30min) | |
| C Spindle Axis | 0.001° Deg. | |
| Tooling Spec. | ||
| Number of Tools | 6 EA | |
| Tool Shank Size | ☐20 mm | |
| Boring Bar Size | 32 mm | |
| Other | ||
| Coolant Tank | 125 L | |
| Required Power | 20 KVA | |
| Machine Height | 2000 mm | |
| Machine Floor Space | 2176 x 1440 | |
| Machine Weight | 2800 KG | |
| Standard Accessories |
| 6" Hydraulic Chuck |
| ID Holder x 4pcs |
| OD Turning Holder x 2pcs |
| Working LED Light |
| 3 step alarm Light |
| Lubrication System |
| Coolant System |
| Hydraulic chucking system |
| Instruction manual |
| Optional Accessories |
| 8" Hydraulic Chuck |
| Power Collet chuck |
| Power Driven Tool (X/Z) |
| Boring bar sleeve |
| U Drill socket |
| Chip Conveyor |
| Part Catcher |
| Auto Barfeeder Interface |
| Oil Skimmer |
| Oil Mist Collector |
| CE Marking |
Design and specification are subject to change without prior notice.
The sound pressure level is 80 dB(A) at the position of one meter outside the machine.
