SG-38
A Highly Rigid Swiss type machine and Excellent For Continuous Precision Machine
Ray Feng Swiss Turning Centers incorporate leading technology and high-quality components, offering optimal solutions for workpieces smaller than 42 mm. The SG-38 stand out with their robust construction, rapid movement, and diverse tooling options. These machines are designed to meet the stringent demands of modern manufacturing with features including:
-High Precision: Ensures excellent accuracy and surface finish for small workpieces.
-Super Rigid Body: Enhances stability and reduces vibration during operation, leading to higher precision and longer tool life.
-Faster Moving: Increased operational speed for improved productivity.
-Variety Tooling Selection: Wide range of tooling options to accommodate different machining requirements.
-Sub-Spindle: Allows for secondary operations, increasing the versatility and efficiency of the machine.
-Live Tooling: Enables complex machining operations without the need to transfer the workpiece to another machine.
- Number of Linear Axes : 6
- Maximum Machining Diameter : 42 mm (N.G.B) ，38 mm(G.B)
- Maximum Number of Driven Tools : 15
- Maximum Number of Tools : 28
- Number of C Axes : 2
- The G.B type can be used to regulate material deflection and achieve accurate machining. For short parts, the N.G.B type can be used to minimize the residual material length and reduce the material cost.
- Design to adopt various toolling options. You can choose optimal tooling to achieve level of productivity. For example Thread Whirling Unit, Polygon Unit, Slotting Unit, etc.
| Model | TYPE A | TYPE B | |
SG-38 | Main Spindle Max. Bar Capacity (Guide Bush Mode) | Ø 38 mm | |
|---|---|---|---|
Main Spindle Max. Bar Capacity (Non-Guide Bush Mode) | 42 mm | ||
Main Spindle Max. Machining Length (One Chucking) | 330 mm | ||
Sub Spindle Max. Bar Capacity | 42 mm | ||
Sub Spindle Workpiece Max. Insertion Length | 120 mm | ||
Sub Spindle Workpiece Max. Protrusion Length | 50 mm | ||
Main & Sub Spindle Max. Speed | 6000 rpm | ||
Main & Sub Spindle Power | 7.5 / 11 kW | ||
All Axis Rapid Feed Rate (Expect Y2) | 30 m / min | ||
Y2 Axis Rapid Feed Rate | 20 m / min | ||
Standard Number of Tools to be Mounted | 22 | 26 | |
Turning Tool (OD Tool) | □20X1pcs、□16X5pcs | ||
Front Dilling Tool (ID Tool) | Ø 32X2 、Ø 25X3 | ||
Rotary Tool | ER20X5 | ||
Deep Hole Drilling Tool | Rotary Tool ER20 x2 Fixed Tool ER20 x2 | Rotary Tool ER20 x4 Fixed Tool ER20 x4 | |
Back Tool Post | 1.5kw | ||
Main Spindle Rotary Tool Motor Power | 1.5kw | ||
Sub Spindle Rotary Tool Motor Power | 1.5kw | ||
Power Consump tion | Power Consumption | 20kva | |
Coolant Tank Capability | 260 L | ||
Floor Space | 3080 x 1680 x 1900 mm | ||
Weight | 4200 kg | ||
Controller | Syntec 220TB / Fanuc Oi TF Plus | ||
| Standard Accessories | |
| Revolving Guide Bush | Parts Conveyor |
| Hydraulic System | Door Interlock System |
| Coolant Flow Detector | Working Light |
| Pneumatic Unit | C-Axis Control |
| (Main & Sub Spindle) | |
| Optional Accessories | |
| CE Marking Version | Non-Guide Bushing Holder |
| Chip Conveyor with Cart | Auto Bar Feeder Machine |
| Long Part Ejector with Guide Tube | High Pressure Coolant Device (30bar/70bar) |
Design and specfication are subject change without prior.
The sound pressure level is dBJA) atthe postion of one meter ourside mahinh.
